Custom 2.7m Crank-and-Tilt Market Umbrella with 38mm Centre Pole

This 2.7m round market umbrella combines a 38mm centre pole, crank opening and tilt adjustment for patio tables and outdoor dining areas. The reference structure uses rectangular 12×18mm ribs and a single air vent.

Model:VST-RXC001-T27

Send Inquiry

Product Description

PRODUCT PARAMETERS

Parameter	Details
Product Type	Round Centre-Pole Market / Table Umbrella

Standard Diameter	2.7 m
Optional Diameters	2.0, 2.3, 2.5 and 3.0 m – frame specification varies
Reference Height	235 cm on one 2.7 m comparison model
Canopy Fabric	160 g/m² polyester
Frame Material	Steel or aluminium options
Centre Pole	Ø38 mm
Rib Section	12 × 18 mm
Rib Count	6 or 8 depending on size and configuration
Opening System	Crank
Tilt	Integrated tilt mechanism
Air Vent	Included on reference configuration
Valance	Optional; confirm canopy pattern
Base	Not included
Reference MOQ	50 Pieces
Packing	Individual protection and export carton;
Water Resistance	Subject to selected fabric, coating and finished-product test
UV Performance	Subject to production fabric test report
Customization	Size, fabric, color, logo, frame finish, valance, base and packaging
Product Origin	China

PRODUCT DETAILS

CRANK OPENING AND TILT ADJUSTMENT

The crank helps operators raise and lower the canopy without a manual push-up hub. The tilt joint changes the canopy angle to respond to lower sun positions. Adjustment range and handle style should be confirmed during sampling.

38MM CENTRE-POLE FORMAT

The approximately 38mm mast is intended for compatible patio-table openings and umbrella bases. Buyers must confirm table-hole clearance, mast connector dimensions and required base weight before ordering.

SIZE AND FRAME OPTIONS

The supplied reference family lists diameters from 2.0m to 3.0m with steel and aluminium variants. Larger sizes may require a different rib count, tube wall thickness, package length and base.

KEY FEATURES

Approx. 2.7m standard canopy diameter

Optional 2.0–3.0m size range

Approx. Ø38mm centre pole

Approx. 12×18mm rectangular ribs

Crank opening mechanism

Integrated tilt adjustment

Single canopy air vent

Steel or aluminium frame options

Custom colors, logos and packaging

CUSTOM DESIGN OPTIONS

Canopy diameter and rib count

Polyester weight, coating and color

Original panel or valance printing

With-valance or without-valance canopy

Powder-coated steel or aluminium frame

Crank housing and tilt-joint specification

Compatible base and protective cover

Barcode labels, instructions and export carton

RECOMMENDED APPLICATIONS

Patio dining tables

Cafés, restaurants and bars

Hotel and resort terraces

Garden centres and outdoor retailers

Wholesalers and private-label collections

WHOLESALE ORDERS

Please provide order quantity, canopy diameter, rib count, fabric, frame material and color, logo file, valance choice, base requirement, packaging and destination country.
